Construction Molding

The result of beautifully shaped, stable concrete and artificial stone castings is based on alkali resistance, efficient reproduction of even and uneven surfaces and long-term durability of the end product. Addition-curing ELASTOSIL® M products are industry benchmarks in this field.

Advantages:
- Exceptional dimensional accuracy / shrink-free
- No need for release agents
- Large number of copies for concrete, artificial stone or gypsum
Applications:
- Facade elements, decorative elements
- Facing bricks for indoor applications
- Matrix / Stamp for imprinting, stamping and texturing concrete
- Tiles
- Bathroom fixtures such as shower basins, sinks
Produktempfehlungen
Produkte
|
Technische Daten
|
Produktmerkmale
|
||||||||
---|---|---|---|---|---|---|---|---|---|---|
dynamische Viskosität | Weiterreißwiderstand | Härte Shore A | Reißfestigkeit | Reißdehnung | Beständigkeit | Regulatorisch | Rheologie | Vernetzungseigenschaft | ||
8000 mPa·s[1] 8000 mPa·s[1] | > 20 N/mm[6] > 20 N/mm[6] | 26[8] 26[8] | 5 N/mm²[11] 5 N/mm²[11] | 500 %[13] 500 %[13] | Beständigkeit gegenüber Beton | Lebensmittelkontakt | Fließfähig | kein chemischer Schrumpf, zweikomponentig, Additionsvernetzend | ||
25000 cP[2] 25000 cP[2] | 31.5 N/mm[6] 31.5 N/mm[6] | 20[9] 20[9] | 7.00 N/mm²[12] 7.00 N/mm²[12] | 800 %[14] 800 %[14] | - | - | - | - | ||
15000 mPa·s[3] 15000 mPa·s[3] | > 30 N/mm[6] > 30 N/mm[6] | 28[9] 28[9] | 6.5 N/mm²[12] 6.5 N/mm²[12] | 700 %[14] 700 %[14] | Beständigkeit gegenüber Beton, Beständigkeit gegenüber Gießharzen | Lebensmittelkontakt | Fließfähig | kein chemischer Schrumpf, zweikomponentig, Additionsvernetzend | ||
20000 mPa·s[3] 20000 mPa·s[3] | > 30 N/mm[6] > 30 N/mm[6] | 37[9] 37[9] | 7 N/mm²[12] 7 N/mm²[12] | 480 %[14] 480 %[14] | Beständigkeit gegenüber Beton, Beständigkeit gegenüber Gießharzen | Lebensmittelkontakt | Fließfähig | kein chemischer Schrumpf, zweikomponentig, Additionsvernetzend | ||
20000 mPa·s[4] 20000 mPa·s[4] | 170 ppi[7] 170 ppi[7] | 37[9] 37[9] | 950 psi[12] 950 psi[12] | 480 %[14] 480 %[14] | - | - | - | - | ||
150000 mPa·s[5] 150000 mPa·s[5] | > 68 lb/in[6] > 68 lb/in[6] | 55[10] 55[10] | 795[12] 795[12] | 300 %[14] 300 %[14] | - | - | - | - | ||
14000 mPa·s[4] 14000 mPa·s[4] | 140 ppi[7] 140 ppi[7] | 22[9] 22[9] | 950 psi[12] 950 psi[12] | 580 %[14] 580 %[14] | - | - | Fließfähig | Schnelle Aushärtung unter Hitze, zweikomponentig, Additionsvernetzend | ||
17000 mPa·s[4] 17000 mPa·s[4] | 110 ppi[7] 110 ppi[7] | 30[9] 30[9] | 900 psi[12] 900 psi[12] | 400 %[14] 400 %[14] | - | - | - | - |
[1] dynamische Viskosität | 23 °C | ISO 3219, [2] dynamische Viskosität nach Umrühren | 23 °C | ISO 3219, [3] dynamische Viskosität aufgerührt | 23 °C | ISO 3219, [4] dynamische Viskosität | 23 °C | Brookfield, [5] dynamische Viskosität after stirring | 23 °C | ISO 3219, [6] Weiterreißwiderstand | ASTM D 624 B, [7] Weiterreißwiderstand | ASTM 624 B, [8] Härte Shore A | DIN ISO 48-4, [9] Härte Shore A | ISO 868, [10] Härte Shore A | ISO 867, [11] Reißfestigkeit | ISO 37 Type 1, [12] Reißfestigkeit | ISO 37, [13] Reißdehnung | ISO 37 Type 1, [14] Reißdehnung | ISO 37
