Medical

VINNAPAS® dispersions can give your end products the specific properties they need for use in medical applications.

Benefits:

  • Hydrophilic properties
  • Pleasant cotton feel
  • High breathability

Applications:

  • Surgical drapes

Product Recommendations

Table is scrollable
Products
Technical data
Product properties
Appearance Hardness Shore A Biocompatibility Tensile strength Elongation at break Tear strength Compression Set Regulation Specific Features Vulcanizate
ELASTOSIL® LR 3003/30 US A/B translucent[1] translucent[1] 31[3] 31[3] - - - - 670 %[6] 670 %[6] 18 N/mm[8] 18 N/mm[8] 18 %[11] 18 %[11] - - -
ELASTOSIL® LR 3003/50 US A/B Transparent[2] Transparent[2] 51 51 - - - - - - 35 kN/m 35 kN/m - - - - -
ELASTOSIL® LR 3003/60 US A/B transparent[1] transparent[1] 59[4] 59[4] - - - - 420 %[6] 420 %[6] 31 kN/m[8] 31 kN/m[8] - - - - -
ELASTOSIL® LR 3003/70 US A/B transparent[1] transparent[1] 68[4] 68[4] - - - - - - 31 kN/m[8] 31 kN/m[8] 18 %[12] 18 %[12] - - -
ELASTOSIL® LR 3003/80 US A/B transparent[1] transparent[1] 77[4] 77[4] - - - - 300 %[6] 300 %[6] 21 N/mm[8] 21 N/mm[8] - - - - -
ELASTOSIL® LR 3078/20 A/B transparent transparent 20[5] 20[5] - - 5.3 N/mm²[14] 5.3 N/mm²[14] 720 %[7] 720 %[7] 11 N/mm[9] 11 N/mm[9] 25 %[13] 25 %[13] - Self-adhesive -
ELASTOSIL® LR 3078/30 A/B transparent transparent 30[5] 30[5] - - 5.9 N/mm²[14] 5.9 N/mm²[14] 660 %[7] 660 %[7] 12 N/mm[9] 12 N/mm[9] 13 %[13] 13 %[13] - Self-adhesive -
ELASTOSIL® LR 3078/40 A/B transparent transparent 40[5] 40[5] - - 7.6 N/mm²[14] 7.6 N/mm²[14] 600 %[7] 600 %[7] 19 N/mm[9] 19 N/mm[9] 19 %[13] 19 %[13] - Self-adhesive -
ELASTOSIL® LR 3078/40 US A/B transparent transparent 40[5] 40[5] - - 8.5 N/mm²[14] 8.5 N/mm²[14] 590 %[7] 590 %[7] 24 N/mm[10] 24 N/mm[10] 11 %[13] 11 %[13] - Self-adhesive -
ELASTOSIL® LR 3078/50 A/B transparent transparent 50[5] 50[5] - - 8.2 N/mm²[14] 8.2 N/mm²[14] 490 %[7] 490 %[7] 21 N/mm[9] 21 N/mm[9] 15 %[13] 15 %[13] - Self-adhesive -
ELASTOSIL® LR 3078/60 A/B transparent transparent 60[5] 60[5] - - 8.9 N/mm²[14] 8.9 N/mm²[14] 460 %[7] 460 %[7] 27 N/mm[9] 27 N/mm[9] 13 %[13] 13 %[13] - Self-adhesive -
ELASTOSIL® LR 3078/70 A/B transparent transparent 70[5] 70[5] - - 7.7 N/mm²[14] 7.7 N/mm²[14] 350 %[7] 350 %[7] 25 N/mm[9] 25 N/mm[9] 10 %[13] 10 %[13] - Self-adhesive -
SILPURAN® FILM 2030 - - 27[5] 27[5] yes[15] yes[15] - - - - - - - - Food-contact, Biocompatible - Precise, Flexible at low (-40 °C) and high temperatures (+180 °C), Electrically insulating, Gas permeable
SILPURAN® FILM 2030 250/100 - - 27[5] 27[5] yes[15] yes[15] - - - - - - - - Food-contact, Biocompatible - Precise, Flexible at low (-40 °C) and high temperatures (+180 °C), Electrically insulating, Gas permeable
Legend
[1] Appearance | DIN ISO 2137,  [2] Appearance | WSTM 2298,  [3] Hardness Shore A | WSTM-1110,  [4] Hardness Shore A | ASTM D 2240 Type A,  [5] Hardness Shore A | DIN ISO 48-4,  [6] Elongation at break | ASTM D 412,  [7] Elongation at break | ISO 37 type 1,  [8] Tear strength | ASTM D 624, Die B,  [9] Tear strength | ASTM D 624 B,  [10] Tear strength | ASTM 624 B,  [11] Compression Set | 22 h | 177 °C ,  [12] Compression Set | 22 h | 177 °C | WSTM 1114,  [13] Compression Set | 22 h | 125 °C | DIN ISO 815-1 type B method A,  [14] Tensile strength | ISO 37 type 1,  [15] Biocompatibility (USP class VI) | ISO 10993,  [] Suited,  [] Well suited,  [] Ideally suited
