Gravure Printing

Gravure printing requires special binders and high-efficiency additives to provide rheology control. Low-molecular-weight VINNOL® resins provide all relevant characteristics, including toughness, permanent flexibility and extreme resistance to abrasion, water and chemicals. HDK® includes hydrophilic grades. To ensure smooth processing, concentrations of 0.5 – 2% are recommended.

Benefits VINNOL®:

  • Excellent pigment wetting
  • Good resistance to chemicals and water
  • Strong adhesion to metals and polar plastics
  • Solubility in ketones and esters
  • High compatibility with other binder resins

Applications:

  • Plastics, metal packaging

Benefits HDK®:

  • Regulation of viscosity
  • Prevention of pigment settling

Applications:

  • High-volume newspapers
  • Catalogues
  • Flyers

Product Recommendations

Table is scrollable
Products
Technical data
BET surface Emulsifier type Supply form Content Appearance Glass transition temperature
HDK® H13L approx. 110 m²/g[1] approx. 110 m²/g[1] - - - - - - - - - -
HDK® H15 approx. 120 m²/g[1] approx. 120 m²/g[1] - - - - - - - - - -
HDK® H20 approx. 170 m²/g[1] approx. 170 m²/g[1] - - - - - - - - - -
HDK® H30 approx. 250 m²/g[1] approx. 250 m²/g[1] - - - - - - - - - -
HDK® N20 175 - 225 m²/g[2] 175 - 225 m²/g[2] - - - - - - - - - -
HDK® T40 360 - 440 m²/g[2] 360 - 440 m²/g[2] - - - - - - - - - -
VINNOL® E 15/40 A - - - - white granulate with some powder[3] white granulate with some powder[3] - - - - approx. 69 °C[4] approx. 156.2 °F[4]
VINNOL® E 15/45 - - - - white granulate with some powder[3] white granulate with some powder[3] - - - - approx. 75 °C[4] approx. 167 °F[4]
VINNOL® E 15/45 M - - - - white granulate with some powder[3] white granulate with some powder[3] - - - - approx. 73 °C[4] approx. 163.4 °F[4]
VINNOL® E 15/48 A - - - - white granulate with some powder[3] white granulate with some powder[3] - - - - approx. 69 °C[4] approx. 156.2 °F[4]
VINNOL® E 18/38 - - - - white granulate with some powder[3] white granulate with some powder[3] - - - - approx. 70 °C[4] approx. 158 °F[4]
VINNOL® E 22/48 A - - - - white granulate with some powder[3] white granulate with some powder[3] - - - - approx. 61 °C[4] approx. 141.8 °F[4]
VINNOL® H 14/36 - - - - white powder[3] white powder[3] - - - - approx. 69 °C[4] approx. 156.2 °F[4]
VINNOL® H 15/42 - - - - white powder[3] white powder[3] - - - - approx. 70 °C[4] approx. 158 °F[4]
VINNOL® H 15/50 - - - - white powder[3] white powder[3] - - - - approx. 74 °C[4] approx. 165.2 °F[4]
VINNOL® H 30/48 M - - - - white powder[3] white powder[3] - - - - approx. 65 °C[4] approx. 149 °F[4]
VINNOL® H 40/43 - - - - white powder[3] white powder[3] - - - - approx. 58 °C[4] approx. 136.4 °F[4]
VINNOL® H 40/50 - - - - white powder[3] white powder[3] - - - - approx. 60 °C[4] approx. 140 °F[4]
WACKER® PRINT AID E 100 - - Nonionic Nonionic - - approx. 58 %[5] approx. 58 %[5] Milky-white Milky-white - -
Legend
[1] BET surface | DIN ISO 9277 DIN 66132 | of the hydrophobic silica,  [2] BET surface | DIN ISO 9277 DIN 66132,  [3] Supply form | Visual,  [4] Glass transition temperature | DSC (DIN 53765 / ISO 11357-5),  [5] Solid content,  [] Suited,  [] Well suited,  [] Ideally suited
